Quick Details

  • Type: Other
  • Brand Name: LOTUSMED
  • Model Number: 500 II
  • Place of Origin: China (Mainland)
  • Syringe Type: 5,10, 20, 30, 50 ml
  • Operating Mode 1): 0.0-999.9ml
  • Accumulated Injection Volume: 0.1 - 999.9 ml
  • Flow Rate Range 1: 5 ml syringe: 0.1 ml/h - 100 ml/h
  • Flow Rate Range 2: 10 ml syringe: 0.1 ml/h - 200 ml/h
  • Flow Rate Range 3: 20 ml syringe: 0.1 ml/h - 400 ml/h
  • Flow Rate Range 4: 30 ml syringe: 0.1 ml/h - 600 ml/h
  • Flow Rate Range 5: 50 ml syringe: 0.1 ml/h - 1500 ml/h
  • Bolus Rate: 10 ml: 100 ml/h,20 ml : 200 ml/h, 50 ml : 500 ml/h
  • KVO Rate: 0.1-5.0ml/h adjustable, 1ml/h as default

Packaging & Delivery

Packaging Details 1 set/carton
Carton size: 40*20*20cm
OEM appointed packages

Best selling High Quality and Competitve Infusion Pump


Product Description


                          Welcome to Nanjing Lotus/LOTUSMED !

Click here for more items: http://chevy-medical.en.alibaba.com




* Compatible with 10ml/20ml/50ml standard syringes as open system

* Micro flow rate until 0.1ml/h with increment of 0.1ml to satisfy the requirement for Neonatal/Pediatric

* Anti-bolus system to reduce significantly bolus after occlusion sudden release

* Reminder alarm in case of forgetting to start the operation

* Alarm volume adjustable on 3 levels

* Wireless data transmission with infusion supervision system





* Three kinds of infusion mode: Rate,Time and Body Wight

* Compatible for all standard syringes of 5ml,10ml,20ml,30ml,50ml

* Drug library with all the most used drugs.

* Change the flow rate while operating

* History record review and last configuration memory

* Rate: 0.1-1500ml/h
* Anti-bolus system




Screen        3.5 inch B/W LCD
Information    Operation Mode, Flow Rate, Accumulated Injection Volume, Syringe Size, Battery Capacity, Bed No., AC power indicator, Battery charge indicator, Stop, Run, Bolus, KVO, Check the Syringe, etc.
Status Indicator  Stop, Run, Bolus, KVO



Alarm Type


Finish, Near, Syringe Empty, Syringe Disengaged, Occlusion, Battery Empty, Low Battery, Reminder to Operate, No AC Power, Errors
Occlusion Alarm Pressure Range     3 levels: 70kPa, 100kPa, 130kPa (±30kPa), Level Low as default





Type                        Lithium polymer battery
Operation Time   Up to 3 hours continuous operation @5 ml/h flow rate with 1600mAh
                                Up to 6 hours continuous operation @5 ml/h flow rate with 2400mAh battery




Temperature     5 - 40 ℃ for operating; -40 - 55 ℃ for storage
Air Pressure     86 - 106 kPa for operating; 50 - 106 kPa for storage
Humidity       20 % - 80 % for operating; 10 % - 95 % for storage





Classification      Class II, Type CF
Dimension        310 mm(L) × 125 mm(D) × 115 mm(H)
Weight           Approximately 1.8 kg
Power Supply      100 - 240 VAC, 0.25-0.11A, 50/60 Hz
Waterproof level    IPX3



Packaging & Shipping


Package : Individual packed in one carton. 1set/carton,

Shipping : By Sea/Air/Express


Our Services

  Choosing us, choosing excellent service.

1.Low MOQ: It can meet your promotional business very well.
2.OEM Accepted: We can produce any your design .
3.Good Service: We treat clients as friends.
4.Good Quality: We have strict quality control system .Good reputation in the market.
5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).

Company Information

We believe: Your success is our success, and our success is your success.


Nanjing Lotus LOTUSMED  is the biggest professional and experienced surgical blades supplier for healthcare in China. High Quality is our pursuit.All our items is coming with certification and we have special team work for after sales services.



Our Team



Customer Alaine How about the lead time?

Answer from Chevy:About 30 working days after receiving the payment and confirming all the artworks, exactly lead time upon the quantity of your order and the packaging you required.

Customer Daniel:Do you have any products in stock?

Answer from Chevy:The products will be produced according to your order.

Customer Hank:Do you have any certificates?

Answer from Chevy:CE and ISO.

Customer Jennifer: What is the best price you can offer?

Answer from Chevy:We always working hard to satisfy our customer, from the quality until the price, as we do understand the market situation. So, please don't hesitate to send your inquiry for us to give you our best price.
