Quick Details

  • Type: Other
  • Brand Name: LOTUSMED
  • Model Number: 500 III
  • Place of Origin: China (Mainland)
  • Syringe Type: 5,10, 20, 30, 50 ml
  • Operating Mode: Flow/Time/ Rate /Body weight/Link Mode
  • Preset Volume: 0.0-999.9ml
  • Accumulated Injection Volume: 0.1 - 999.9 ml
  • Flow Rate Range: 5 ml syringe: 0.1 ml/h-100 ml/h
  • Increment: 0.1ml/h
  • KVO Rate: 0.1-5.0ml/h adjustable,1ml/h as default
  • Drug library: Drug library
  • History record: 1500 records (Operation status, Infusion Information, Alarms)
  • Saved syringe brands: 15 brands

Packaging & Delivery

Packaging Details: 1 set/carton
Carton size: 40*30*25cm
OEM appointed packages

Best selling High Quality and Competitve Infusion Pump



Product Description



                          Welcome to Nanjing Lotus/LOTUSMED !

Click here for more items: http://chevy-medical.en.alibaba.com



 Features



*Designed for multiple drug injection application (up to 8 pumps)

*Only one power cord for multi-channel pumps Innovative Link Mode offers continuous injection to improve safety for patients
*Drug library with all the most used drugs History record review and last configuration memory
*Anti-bolus system to reduce significantly bolus after occlusion release
*Change the flow rate while operating Manual bolus and automatic bolus Wireless data transmission with infusion supervision system and bedside workstation



Descriptions



* Four kinds of injection modes:Rate mode,Body Weight mode,link mode.

* Compatible for all standard syringes of 5ml,10ml,30ml,50ml.

* Rate range: 0.1-1500ml/h

* Big LCD,clear iinformation.

* KVO:0.1--5.0ml/h(selectable)

* Bolus rate:100-1500ml/h
*Various alarm function

  Display



Screen

Independent 3.0 inch color TFT screen for each pump channel

Information

Operation Mode, Flow Rate, Accumulated Injection Volume, Syringe Size, Battery Capacity, Bed No., AC power indicator, Battery charge indicator, Check the Syringe, etc.

Status Indicator

Stop, Run, Bolus, KVO









Alarm Type



Finish, Near, Syringe Empty, Syringe Disengaged, Occlusion, System Error, Battery Empty, Low Battery, Reminder to operate, No AC Power
Occlusion Alarm Pressure Range     3 levels: 70kPa, 100kPa, 130kPa (±30kPa), Level Low as default





Battery



Type                        Lithium polymer battery
Life  Up to 2 hours continuous operation @5 ml/h flow rate with standard battery

Environment



Temperature     5 - 40 ℃ for operating; -20 - 50 ℃ for storage
Air Pressure     86 - 106 kPa for operating; 50 - 106 kPa for storage
Humidity       20 % - 80 % for operating; 10 % - 95 % for storage





  Others



Classification      Class II, Type CF
Dimension        310 mm(L) × 110 mm(D) × 200 mm(H)320mm(L)×110MM(D)×400mm(H)320mm(L)

Weight          3.4 kg        7.0kg        10.4kg
Power Supply      100 - 240 VAC, 50/60 Hz
Waterproof level    IPX3



Packaging & Shipping



Package : Individual packed in one carton. 1set/carton,

Shipping : By Sea/Air/Express



Our Services

  Choosing us, choosing excellent service.

1.Low MOQ: It can meet your promotional business very well.
2.OEM Accepted: We can produce any your design .
3.Good Service: We treat clients as friends.
4.Good Quality: We have strict quality control system .Good reputation in the market.
5.Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).

Company Information

We believe: Your success is our success, and our success is your success.



Nanjing Lotus LOTUSMED  is the biggest professional and experienced surgical blades supplier for healthcare in China. High Quality is our pursuit.All our items is coming with certification and we have special team work for after sales services.





Our Team

FAQ



Customer Alaine How about the lead time?

Answer from Chevy:About 30 working days after receiving the payment and confirming all the artworks, exactly lead time upon the quantity of your order and the packaging you required.

Customer Daniel:Do you have any products in stock?

Answer from Chevy:The products will be produced according to your order.

Customer Hank:Do you have any certificates?

Answer from Chevy:CE and ISO.

Customer Jennifer: What is the best price you can offer?

Answer from Chevy:We always working hard to satisfy our customer, from the quality until the price, as we do understand the market situation. So, please don't hesitate to send your inquiry for us to give you our best price.
